AAA+ Pre-Wired Harness for Gibson Les Paul
From a Guitar-Tech standpoint we, at Carparelli Guitars, felt the need to create our own homegrown Pre-Wired Kits for the Guitar/Bass World.
All the Carparelli Pre-Wired Harnesses are professionally hand soldered right here in our Canadian Shop. Each Kit is templated for a smooth drop-in retrofit.
We believe at this point we are the first for using the PURETONE Multi Contact output Jack and for saving you more time and convenience we've also added a 10" AeroSpace grade 22g bridge ground wire.
This is our AAA High Grade Kit just a notch under our AAAA Supreme High Grade Kit.
What's in the Kit?
4 x 500K ohm audio pot, 3/4" long threaded bushing CTS split shaft
2 x 0.022uf Orange Drops Capacitors
1 x Switchcraft 3 Way Toggle Short Toggle Switch
1 x PureTone Multi Contact output Jack
5 x Extra Hex 3/8 32 thread count Nuts
1 x Aerospace grade bridge ground wire
16g Bus Wire ( Ground )
Cloth Push Back Wire
Before the kit leaves the door, they are all TESTED and 100% Guaranteed. We will refund you 100% if you are not completely satisfied with your harness kit.
The kit also comes with a reusable hardboard template covered in copper foil which in itself can be used and save for future wiring jobs should you take
that on one day! The Template is great for holding the components correctly and accurately to fit neatly into your guitar wiring cavity.
We really want you to have a stress free enjoyable experience so you can start rockin out!
Product Specs:
Switchcraft Toggle Switch Specs
Body cavity depth 1-1/2" (38.10mm)
Mounting hole diameter 1/2" (12.70mm)
Thread height 7/32" (5.56mm)
CTS Control Pot Specs
Resistance 500K-ohm
Shaft diameter 0.235" (5.95mm)
split shaft, fine knurling
Thread 3/8" x 32
Threaded portion 3/8" (9.52mm)
Threaded portion, long shaft 3/4" (19.05mm)
Required mounting hole diameter 3/8" (9.52mm)
Orange Drop Capacitor Specs:
Value .022uF Code 223K
PURETONE Multi Contact Output Jack Specs:
Accepts standard 1/4" plugs Mono
Mounting hole diameter 3/8" (9.52mm)
Thread 3/8 x 32
Threaded portion height 1/4" (6.35mm)
